L2 Features
|
Port configuration
|
Auto-negotiation
|
|
|
Flow Control
|
|
|
Port Mirror
|
|
|
Traffic statistics
|
|
|
Link Aggregation
|
Static link aggregation
|
|
|
LACP
|
|
|
Algorithm based on Source/Destination MAC
|
|
|
Algorithm based on Source/Destination IP
|
|
|
8 groups
|
|
|
8 ports per group
|
|
|
MAC Table
|
Aging Time
|
|
|
Static MAC address
|
|
|
Dynamic MAC address management
|
|
|
VLAN
|
4K Active VLANs
|
|
|
4K VID
|
|
|
802.1Q Tag VLAN
|
|
|
Port VLAN
|
|
|
Protocol VLAN
|
|
|
MAC VLAN
|
|
|
Management VLAN
|
|
|
Voice VLAN
|
|
|
Q-in-Q
|
|
|
Private VLAN
|
|
|
GARP/GVRP
|
|
|
ACL
|
64 ACLs
|
|
|
L2, L3 e L4
|
|
|
Time-based ACL
|
|
|
Spanning tree
|
802.1D Spanning Tree Protocol (STP)
|
|
|
802.1w Rapid Spanning Tree Protocol (RSTP)
|
|
|
802.1s Multiple Spanning Tree Protocol (MSTP)
|
|
|
Loop Guard
|
|
|
Root Guard
|
|
|
TC-BPDU Guard
|
|
|
BPDU Guard
|
|
|
BPDU Filter
|
|
|
Multicast
|
256 groups
|
|
|
IGMP v1/v2/v3
|
|
|
Fast Leave
|
|
|
Multicast VLAN
|
|
|
Static Multicast
|
|
|
Multicast Filter
|
|
|
IGMP Statistics
|
|
|
MLD Snooping
|
|
|
PoE management
|
Support total power consumption control
|
|
|
Support single port PoE ON/OFF
|
|
|
Support port output priority
|
|
|
QOS
|
4 priority queues
|
|
|
CoS port-based
|
|
|
CoS 802.1p-based
|
|
|
CoS DSCP-based
|
|
|
Scheduling algorithms SP, WRR, SP+WRR
|
|
|
Storm Control (Broadcast, Multicast, Unknown Unicast)
|
|
|
Bandwidth control per port
|
|
|
Security Features
|
Port Security
|
|
|
MAC address filter
|
|
|
ARP Association (Manual, ARP scanning, DHCP snooping) up to 200 entries
|
|
|
ARP Protection
|
|
|
DoS (Denial of Service)
|
|
|
Classification of packages based on: End.MAC, IP End, TCP / UDP Ports,
Protocol Type
|
|
|
802.1x Autentication (port-based e MAC-based)
|
|
|
TACACS/TACACS+ Autentication
|
|
|
RADIUS Autentication
|
|
|
DHCP Filter
|
|
|
Guest VLAN
|
|
|
SSLv2/SSLv3/TLSv1
|
|
|
SSHv1/SSHv2
|
|
|
Restriction of WEB access based on: IP Address, And. MAC and Port
|
|
|
Port Isolation
|
|
|
Local User Name Password Authentication (2 levels)
|
|
|
Loopback detection
|
|
|
Management
|
SNMP v1/v2c/v3
|
|
|
RMON 4 grupos
|
|
|
WEB (HTTP/HTTPS)
|
|
|
CLI (Telnet,
Console, SSHv1/v2)
|
|
|
Firmware upgrade
via console/web/TFTP
|
|
|
Configuration
Backup/Reload
|
|
|
All possible
configurations in the CLI must exist in the WEB interface
|
|
|
LLDP
|
|
|
Other
Features
|
DHCP Relay
|
|
|
DHCP Client
|
|
|
DHCP Snooping
|
|
|
DHCP Option 82
|
|
|
SNTP Client
|
|
|
BOOTP Client
|
|
|
Maintenance
|
Ping and Tracert
|
|
|
System log (Local
and Remote)
|
|
|
Memory and CPU
Monitoring
|
|
|
L3
Features
|
Static Routing
|
|
|
OSPFv2
|
|
|
RIPv1/v2
|
|
|
DHCP Server
|
|
|
IPV6
|
IPv6 neighbor
discovery (ND)
|
|
|
Path maximum
transmission unit (MTU) discovery
|
|
|
Internet Control
Message Protocol (ICMP) version 6
|
|
|
TCPv6/UDPv6
|
|
|
Ping6
|
|
|
Tracert6
|
|
|
Telnet(v6)
|
|
|
Http/Https
|
|
|
IPv6 TFTP
|
|
|
Static Routing
|
|
|
Interface IPV6
|
|
